Packaging Injection Molding Solutions

Injection molding solutions for packaging

In addition to the aforementioned products, FCS also offers injection molding solutions for disposable food tableware, cosmetics, and packaging containers for daily chemical solvents. Our diverse range of solutions is designed to meet the demands of mass production while ensuring stability and consistent yield.

Advantages of FCS injection molding machines in the packaging industry

Energy-efficient

Stable production

Reliable and durable

Customized turnkey solution

Thin-wall food container

Disposable cup

Disposable tableware

IML chocolate bucket with cover

IML yogurt cup (lid with spoon)

Two-color bucket cover

Caps

PET preform

Two-color shampoo cap

Sprayer accessories

Cosmetic container

Paint bucket

Explore injection molding solutions for various packaging containers

Production of packaging

Solution

PET Preform Injection Molding Machine (HT-P Series)

PET material design, increase the screw diameter and LD ratio, raise the injection volume and charging rate.
It mainly specialized for 24 to 96 cavities preforms, with the configuration of electric charging, forming a double loop (mold opening while charging), cycle time shortened about 4 to 6 seconds.
It can be used with molds, blowing, filling, packaging and other equipment to provide customers with turnkey solutions.
This series is broadly applicable for producing various PET preforms, such as water bottles, hot-filled bottles, cooking oil bottles, wide mouth bottles, and 5- gallon large performs... etc.

High-Speed Thin-Wall Injection Molding Machine (SA-h Series)

High rigidity platen mechanism, less deformation, lower clamping force.
Standard high-speed proportional valve, with fast mold open response, accurate positioning and short cycle time.
The pipelines adopt no welding processing, decreasing the risk of oil leaking.
Improving the cleanness of oil circuits and increase machine life.
Equipped with a KEBA control system, featuring an operation mode scan of less than 1 ms, ensuring precise and stable machine operation.
Standard infrared heater, fast heating, good heat preservation, energy saving over 30%.
Adopt PID temperature control within ±1℃.
Adopt higher L/D radio, highly mixing screw and good plasticization efficiency.
The injection carriage adopts linear guides, ensuring precise and stable operation.
The medium-inertia single-cylinder injection mechanism, fast response and high repeatability.
Equipped with high performance servo power system, energy saving about 30% to 70%.
Unique modular design, easy maintainanece.
Optionally equipped with double loops system, shorten the cycle time to the greatest extent.

All-Electric Injection Molding Machine (CT-e Series)

The high-performance servo system and controller make injection accuracy up to 0.01 mm.
Ensure highly-responsive injection unit offers optimized pressure closed-loop algorithm.
The injection carriage adopts linear guides, ensuring precise and stable operation.
Full servo motor drive design with high efficiency and stability, which is first level energy saving.
Tie bars are not embedded in platen to reduce pollution and abrasion, which is suitable for medical products.
Parallel movement of ejector while mold opening is standard, effectively shorten the cycle time.
Intelligent mold clamp low-pressure protection, reduce the risk of mold crush.
Mold adjusting adopts closed-loop servo valve for faster and precise operation.
Optional modular specification offers flexible injection unit combination.
21.5 inch touch screen and new controller interface make it easy to operate.
